4k Hikvision 16ch 8mp Colorvu Ip Camera System

>Hikvision APP : hik-connect, guard viewer, IVS-4200 >Search Tool：SADP （search device and change IP address） >Warranty: 3years >If there is any problem with use, please contact with us at any time. we have very professinal engineer, can help you set online. >>> The NVR is 100% Hikvision Original, can support firmware upgrade; >>> This camera is Hikvision OEM Version, remove Hikvision logo on the box and come with yellow box. support OEM upgrade. All function and quality are same as Hikvision Original.  >>> All the items are with 3 years warranty, if there is any problem after purchased, please contact us for help. Hikvision OEM 8MP ColorVu Strobe Light and Audible Warning Fixed Turret Network Camera High quality imaging with 8 MP resolution Efficient H.265+ compression technology Clear i
4K Hikvision 16CH 8MP Colorvu IP Camera System MIC+Audio Alarm Speaker NVR Lot >Hikvision APP
: hik-connect, guard viewer, IVS-4200 >Search Tool
：SADP （search device and change IP address） >Warranty: 3years > If there is any problem with use, please contact with us at any time. we have very professinal engineer, can help you set online. >>> The NVR is 100% Hikvision Original, can support firmware upgrade; >>> This camera is Hikvision OEM Version, remove Hikvision logo on the box and come with yellow box. support OEM upgrade. All function and quality are same as Hikvision Original. >>> All the items are with 3 years warranty, if there is any problem after purchased, please contact us for help. Hikvision OEM 8MP ColorVu Strobe Light and Audible Warning Fixed Turret Network Camera High quality imaging with 8 MP resolution Efficient H.265+ compression technology Clear imaging against strong backlight due to 130 dB WDR technology Focus on human and vehicle targets classification based on deep learning 24/7 colorful imaging Active strobe light and audio alarm to warn intruders off Provide real-time security via built-in two-way audio Audio and alarm interface available Water and dust resistant (IP67) Hikvision Original 16CH 16 POE DS-7616NI-K2/16P Embedded Plug & Play 4K NVR

Up to 16 channel IP cameras can be connected

Supports decoding H.265+/H.265/H.264+/H.264 video formats

Up to 4K high-definition live view, storage and playback

Up to 8-ch /1080p decoding capacity

Up to 160 Mbps high incoming bandwidth ensures IP cameras can be connected

1 HDMI and 1 VGA interfaces: both interfaces support independent video output

2 HDDs for continuous video recording

Compatible with third-party network cameras

Plug & Play with 8 Power-over-Ethernet (PoE) interfaces

Supports various specific function cameras, including thermal camera /fisheye/people counting/heatmap/ANPR (automatic number plate recognition)

Channel-zero function ensures smooth remote live view and playback in low bandwidth environments

NVR: DS-7616NI-K2/16P Video And Audio IP Video Input 16-ch Incoming Bandwidth 160 Mbps Outgoing Bandwidth 160 Mbps HDMI Output 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz VGA Output 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz Audio Output 1-ch, RCA (Linear, 1 KΩ) Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1kΩ) Decoding Decoding Format H.265/H.265+/H.264/H.264+/MPEG4 Recording Resolution 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Synchronous Playback 16-ch Decoding Capability 2-ch @ 8 MP (25fps) / 4-ch @ 4MP (30fps) / 8-ch @ 1080p (30fps) Network Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS Network Interface 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface PoE Interface 16, RJ-45 10/100 Mbps self-adaptive Ethernet interface Power ≤ 200 W Standard IEEE 802.3 af/at Auxiliary Interface SATA 2 SATA interfaces Capacity Up to 6 TB capacity for each HDD Alarm In/Out 4/1 USB Interface Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 General Power Supply 100 to 240 VAC，50 to 60Hz, 1 A Consumption ≤ 15 W (without enabling PoE and HDD) Working Temperature -10 °C to 55 °C (14 °F to 131 °F) Working Humidity 10 to 90 % Dimension (W × D × H) 385 × 315 × 52 mm (15.2" × 12.4" × 2.0") ≤ 3 kg (6.6 lb, without HDD) Camera Image Sensor 1/1.2″ Progressive Scan CMOS Max. Resolution 3840 × 2160 Min. Illumination Color：0.0005 Lux @ (F1.0, AGC ON)，0 Lux with white light Shutter Speed 1/3 s to 1/100,000 s Day & Night 24/7 Color imaging Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° Lens Lens Type Fixed focal lens, 2.8 and 4 mm optional Focal Length & FOV
2.8 mm, horizontal FOV 102°, vertical FOV 52°, diagonal FOV 124°
4 mm, horizontal FOV 88°, vertical FOV 47°, diagonal FOV 104° Lens Mount M mount Iris Type Fixed Aperture F1.0 Depth Of Field
2.8 mm: 4 m to ∞
4 mm: 6.2 m to ∞ DORI DORI
2.8 mm: D: 96 m, O: 38 m, R: 19 m, I: 9 m
4 mm: D: 102 m, O: 40 m, R: 20 m, I: 10 m Illuminator Supplement Light Type White Light Supplement Light Range Up to 30 m Smart Supplement Light Yes Video Main Stream
50 Hz:
25 fps (3840 × 2160, 3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
24 fps (3840 × 2160)
30 fps (3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720) Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360) Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 x 1080, 1280 × 720, 640 × 480, 640 × 360) Video Compression
Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264 Video Bit Rate 32 Kbps to 16 Mbps H.264 Type Baseline Profile/Main Profile/High Profile H.265 Type Main Profile Bit Rate Control CBR/VBR Scalable Video Coding (SVC) H.264 and H.265 encoding Region Of Interest (ROI) 1 fixed region for main stream and sub-stream Audio Environment Noise Filtering -U: Yes Audio Sampling Rate -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Audio Compression -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC Audio Bit Rate -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) Network Simultaneous Live View Up to 6 channels API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK , ISUP Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets User/Host Up to 32 users. 3 user levels: administrator, operator and user Security Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface Network Storage NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Client iVMS-4200, Hik-Connect, Hik-Central Web Browser
Plug-in required live view: IE 10, IE 11
Plug-in free live view : Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+ Image Wide Dynamic Range (WDR) 130 dB SNR ≥ 52 dB Privacy Mask 8 programmable polygon privacy masks, mask color or mosaic configurable Day/Night Switch Day, Night, Auto, Schedule Image Enhancement BLC, HLC, 3D DNR Image Parameters Switch Yes Image Settings Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser Interface Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256 GB Built-In Microphone Yes Built-In Speaker 1.5 W, 10 cm: 95 dB Audio
1 input (line in), max. input amplitude: 3.3 Vpp, input impedance:4.7 KΩ, interface type: non-equilibrium
1 output (line out), max.output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium Alarm 1 input, 1 output (max. 24 VDC, 1 A) Reset Key Yes Event Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) Smart Event Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human and vehicle)), scene change detection Linkage Upload to NAS/memory card/FTP, notify surveillance center, trigger record, trigger capture, send email Deep Learning Function Face Capture Yes General Power
12 VDC ± 25%, 0.63 A, max. 8.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: 802.3af, Class 3, 36 V to 57 V, 0.24 A to 0.15 A Material Cover: metal, main body: metal Dimension Ø138.3 mm × 120.1 mm (Ø5.4" × 4.7") Package Dimension 170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9") Approx. 900 g (2 lb.) With Package Weight Approx. 1190 g (2.6 lb.) Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Startup And Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Language
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian General Function Anti-flicker, heartbeat, mirror, password reset via e-mail, pixel counter Approval EMC
FCC (47 CFR Part 15, Subpart B)
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014)
RCM (AS/NZS CISPR 32: 2015)
IC (ICES-003: Issue 7)
KC (KN32: 2015, KN35: 2015) Safety
UL (UL 62368-1)
CB (IEC 62368-1: 2014+A11)
CE-LVD (EN 62368-1: 2014/A11: 2017) Environment
CE-RoHS (2011/65/EU)
WEEE (2012/19/EU)
Reach (Regulation (EC) No 1907/2006) Protection IP67: IEC 60529-2013 24/7 full-time Color The 24/7 full-time Color night vision ip camera adopted the full color technology, with advanced lenses, high performance sensors and built-in warm supplemental lighting, providing 24hr colorful image in ultra-low illumination condition, even get the live view full color image in total darkness by the automaticly supplemental lighting up. Ultra 8MP High HD Resolution Observe high-quality footage with a 1/1.2″ Progressive Scan CMOS , Ultra HD 8MP- Resolution (3840 × 2160@30fps) Provide a more HD and smoother visual experience. Acusense Technology and Strobe Light and Audio Alarm The Acusense 8MP Camera by the cutting-edge AI algorithms technology, when a potential threat is detected by the camera, it uses its intelligent false alarm reduction technology to disregard irrelevant movements, such as rain, leaves and animals.Active strobe light and audio alarm warn intruders off promptly. Focus on human and vehicle targets classification based on Empowered by deep learning algorithms, Hikvision AcuSense technology brings human or vehicle target classification alarms to front- and back-end devices. The system can greatly reduce false alarms generated by targets other than humans or vehicles, vastly improving alarm efficiency and effectiveness Two-Way Speaking & 120dB WDR 4K UltraHD Camera built-in Mic andspeaker with two way audio,greet quest orscare off intruders wherever your are. This poe camera uses the industry's leading 120dB Wide Dynamic Range (WDR) technology to produce vivid images even under the strongest contrast lighting conditions. Ultra HD Resolution ，Smart265+ Smart H.265 technology reduces bit rate and storage requirements by up to 70% when compared to standard H.265 video compression Motion detection&P2P
The camera support the motion detection，recording by the alarm detection， Camera can easy to add the camera to mobile phone via APP，Preview in real time no matter where you are Easy to use
T he camera is Hikvsion original version, 100% English version, compatible with Hikvision and other brand protocol，
the camera can Plug and play with Hikvison NVR, Power Over Ethernet (POE) for easy installation IP67 Weatherproof
Equipped with an ip67 rated weatherproof outer casing, designed to operate the camera even in extreme weather conditions. Support On-vif The camera is Hikvision 100% Original version camera, English Version, can plug and play with Hikvision NVR.
And support use with third party NVR.

Returns Accepted for this item if it's within 30 Days
